Soundcraft UI16
Delivery & payment
- Pickup at the school
- Free · 9:00–21:00
- Ho Chi Minh City
- Fee confirmed with your order
- Across Vietnam
- Courier · fee confirmed by phone
- Payment
- VietQR · cash on delivery · pay at the school
Warranty Genuine product, official warranty, 7-day exchange for factory faults.
- Type
- Digital mixer controlled from a browser over Wi-Fi
- Inputs
- 8 × XLR/jack combo mic/line, 4 × XLR mic, 2 × Hi-Z instrument, 1 × stereo RCA line
- Outputs
- Main L/R on balanced XLR and 6.35 mm jack; 4 × balanced XLR aux; 2 × 6.35 mm headphones with level control
- Control
- Built-in Wi-Fi and Ethernet (RJ45), usable at the same time; up to 10 devices on iOS, Android, Windows, macOS, Linux
- Input processing
- 4-band parametric EQ, high-pass filter, compressor, de-esser, noise gate; recallable gain and phantom power
- Output processing
- 31-band graphic EQ, compressor, noise gate, dbx AFS2; RTA on inputs and outputs
- Effects
- Lexicon reverb, delay and chorus; DigiTech amp modelling
- USB media
- 2-channel playback (MP3, WAV, AIFF) and stereo recording to a USB drive
- Frequency response
- 20 Hz – 20 kHz, ±0.25 dB
- Latency
- 1.8 ms (mic in to line out)
- Mixer functions
- Subgroups, mute groups, view groups, snapshots with channel safes, footswitch FX mute
- Power supply
- External adapter with locking ring, 88–265 V AC; under 25 W typical
- Dimensions (H × W × L)
- 110 × 177 × 483 mm
- Weight
- 3.61 kg
Description
The Soundcraft Ui16 is a 16-input digital mixer controlled entirely from a browser on a tablet, phone or computer. With no physical control surface, the box can sit on stage next to the performers while you mix from anywhere in the room over its built-in Wi-Fi.
Highlights
- 8 XLR/jack combo mic/line inputs, 4 XLR mic inputs, 2 Hi-Z instrument inputs and a stereo RCA line input
- 4 balanced XLR aux outputs, main outputs on XLR and jack, two headphone outputs with level control
- As many as 10 phones, tablets or computers can control it simultaneously (iOS, Android, Windows, macOS, Linux), with password-protected access limits
- Every input gets a high-pass filter, 4-band parametric EQ, noise gate, compressor and de-esser, and its gain and phantom power can be recalled
- Per output: 31-band graphic EQ, compressor and noise gate, plus dbx AFS2 feedback suppression and an RTA
- Lexicon reverb, delay and chorus, DigiTech amp modelling, snapshots with channel safes
In your setup
Join the mixer's own Wi-Fi hotspot, an existing network, or a wired LAN through the Ethernet port, then open its control page in a browser; nothing has to be installed. The four aux outputs can carry separate monitor mixes, and each musician can adjust their own mix from a phone while being locked out of the rest. A DJ mixer or player goes into the stereo RCA input, and a guitar or bass can plug straight into a Hi-Z input. A USB drive on the front panel plays MP3, WAV or AIFF files and records the stereo master; Soundcraft describes the USB ports for media, show files and firmware updates rather than as a computer audio interface. Power comes from an external adapter with a locking connector.
