JBL EON 615
Delivery & payment
- Pickup at the school
- Free · 9:00–21:00
- Ho Chi Minh City
- Fee confirmed with your order
- Across Vietnam
- Courier · fee confirmed by phone
- Payment
- VietQR · cash on delivery · pay at the school
Warranty Genuine product, official warranty, 7-day exchange for factory faults.
- Type
- Self-powered 15" two-way bass-reflex PA speaker
- Drivers
- JBL 615H 380 mm (15") woofer, 2" voice coil; JBL 2414H-1 25.4 mm (1") polymer-diaphragm neodymium compression driver
- Power
- 1000 W peak (700 W LF + 300 W HF), 500 W continuous (350 W LF + 150 W HF), Class D
- Frequency response
- 50 Hz – 20 kHz (±3 dB); 39 Hz – 20 kHz (-10 dB)
- Max SPL
- 127 dB
- Crossover
- 1.8 kHz
- Inputs
- 2 × balanced XLR-1/4" combo (mic/line), no phantom power
- Outputs
- 1 × male XLR loop thru
- DSP
- Presets Main, Monitor, Speech, Subwoofer; Bluetooth control: 3 parametric EQ + hi/lo shelf, gain, delay, save/recall
- Enclosure
- Black polypropylene, 4 handles, powder-coated perforated steel grille
- Mounting
- 35 mm pole socket, 3 × M10 suspension points, monitor angle on both sides
- Power supply
- 100–120 V AC or 230–240 V AC, 50/60 Hz
- Dimensions
- 707 × 439 × 365 mm
- Weight
- 17.69 kg
Description
The JBL EON615 is a self-powered 15-inch two-way PA speaker from JBL Professional's EON600 series, built for mobile DJs, bands and event crews who need one box that can serve as a main speaker, a stage monitor or a side fill. JBL now lists the model as discontinued.
Highlights
- JBL 615H 15-inch woofer with 2-inch voice coil and JBL 2414H-1 1-inch neodymium compression driver, 1.8 kHz crossover
- 1000 W peak (700 W LF + 300 W HF), 500 W continuous, Class D
- Up to 127 dB SPL; 50 Hz – 20 kHz (±3 dB), 39 Hz – 20 kHz (-10 dB)
- DSP presets Main, Monitor, Speech and Subwoofer
- Bluetooth control from iOS and Android: 3 parametric EQ bands plus high and low shelf, gain, delay, save and recall, up to 4 speakers at once
- Polypropylene cabinet, four handles, 35 mm pole socket and three M10 suspension points
For a DJ set, plug the master output of a mixer or controller into one of the two combo XLR-1/4" inputs and pass the signal to a second speaker through the male XLR loop thru. The inputs accept mic or line level but offer no phantom power, so condenser microphones should go through a mixer. Bluetooth on this speaker is for remote control of the DSP, not for streaming music.
The cabinet can lie on either side as a floor wedge, sit on a speaker pole via its 35 mm socket or be flown from the M10 points, which makes it practical for parties, speeches, small venues and rehearsal rooms. It weighs 17.69 kg, measures 707 × 439 × 365 mm and has four handles for carrying.
